Introduction:

 ● Symmetrical TX and RX channels for auto MDI/MDIX capability.

● Approved for use with Broadcom BCM5226/BCM5228 and Level One LXT9784.
● Primary inductance(Lp)350uH min.@ 100KHz,0.1Vrms,DC 8mA.
● LL:0.5uH Max @100KHz, 0.1V.
● Cww:75pF Max@100KHz, 0.1V.
● Primary DCR:0.9ΩMax;Secondary DCR:1.2ΩMax.
● Storeage Temperature -25℃ to +125℃.
● RoHS compliance.
